Dimensions
| Type | A | B | C | D | N* | ØE |
|---|---|---|---|---|---|---|
| mm | mm | mm | mm | mm | mm | |
| KR AFC/Compact 250 | 806 | 63 | 770 | 710 | 16 | 12 |
| KR AFC/Compact 315 | 806 | 63 | 770 | 710 | 16 | 12 |
| KR AFC/Compact 355 | 806 | 63 | 770 | 710 | 16 | 12 |
| KR AFC/Compact 400 | 806 | 63 | 770 | 710 | 16 | 12 |
| KR AFC/Compact 450 | 806 | 63 | 770 | 710 | 16 | 12 |
| KR AFC/Compact 500 | 806 | 63 | 770 | 710 | 16 | 12 |
| KR AFC/Compact 560 | 806 | 63 | 770 | 710 | 16 | 12 |
| KR AFC/Compact 630 | 806 | 63 | 770 | 710 | 16 | 12 |
| KR AFC/Compact 710 | 810 | 63 | 760 | 710 | 12 | 12 |
| KR AFC/Compact 800 | 911 | 63 | 850 | 800 | 12 | 12 |
| KR AFC/Compact 900 | 1000 | 75 | 950 | 900 | 12 | 12 |
| KR AFC/Compact 1000 | 1100 | 75 | 1050 | 1000 | 12 | 12 |
| KR AFC/Compact 1120 | 1100 | 75 | 1050 | 1000 | 12 | 12 |
| KR AFC/Compact 1250 | 1100 | 75 | 1050 | 1000 | 12 | 12 |
